- Standard: Third party approved acc. to relevant Norwegian aquaculture standards
- Material: High Tensile Steel. Quenched and Tempered, Grade 6
- Finish: All parts hot dip galvanized + brown colour marking
All dimensions in mm
Part no | MBL tonnes | dim. | L | G | E | T | Weight kg |
A825232 | 40 | Ø32 | 400 | 72 | 35 | 300 | 5.5 |
A825238 | 60 | Ø38 | 500 | 84 | 42 | 350 | 9 |
A825445 | 80 | Ø45 | 500 | 105 | 45 | 400 | 13.2 |
A825245 | 80 | Ø45 | 600 | 105 | 45 | 400 | 14.3 |
A825450 | 100 | Ø50 | 500 | 100 | 45 | 400 | 13.3 |
A825250 | 100 | Ø50 | 700 | 110 | 50 | 400 | 20.3 |
A825256 | 130 | Ø56 | 800 | 127 | 50 | 400 | 30.3 |
A825265 | 170 | Ø65 | 800 | 140 | 58 | 400 | 38.3 |
